Active Electronically-Scanned Arrays – AESAs
(Markets within the “Free” – Western – World)
The AESAs4 Report (code: AESAs4)
This report follows the already successful trio of industry and market reports published since 2006 by Engalco on this subject: AESAs(1), AESAs2 and AESAs3. A major change with AESAs4 is that this comprises five sub-modules:
· The Common Module (CM).
· Airborne AESAs.
· Land-based AESAs.
· Shipboard AESAs.
· Worldwide AESAs Markets.
For all AESAs that are designed for specific platforms (airborne or shipboard) each platform was identified in detail as well as the AESA system. On the basis of as much hard data as could be determined the markets for each AESA system were forecasted out to 2017. This forecasting applies to all AESAs identified during the research: airborne, land-based (many being truck-mounted) and shipboard.
Data are also segmented by frequency band (L, S, C, X, Ku).
Detailed column charts of data are embedded within each module except the common module. Data points are included on the tops of columns relating to geographically total markets.
You can purchase the entire report (i.e. all five modules together) for $3,480.
The Common Module is priced at US$1,500 and each of the other modules is individually priced at US$1,790 (single-user in all instances). THESE ARE ALL 40% REDUCTIONS EFFECTIVE FROM September 22, 2014
The Common Module (CM):
· Brief description as to what an AESA is.
· Frequency bands – cross-referenced.
· Transmit-receive modules (TRMs).
· Hybrid microwave integrated circuits (HMICs).
· The significance of MMICs (GaAs, GaN, SiGe).
· Important technology trends.
· Supply chains.
· Profiles of contractors and OEMs.
Airborne AESAs:
As many as possible airborne AESAs identified:
#15 in Europe, #15 in USA.
Column charts of annual shipments & monetary markets (including forecasts to 2017) for:
The AESA systems.
TRMs within these AESA systems.
The airborne AESAs identified are:
Table 1 Europe (includes Israel):
|
Captor-E
|
EL/M-2052
|
EL/M-2083
|
EL/M-2085
|
EL/W-2085 (L-band)
|
EL/W-2085 (S-band)
|
EL/W-2090
|
Erieye
|
|
picoSAR
|
RAVEN ES-05
|
RBE2 (AA)
|
Seaspray 5000E
|
Seaspray 7000E
|
Seaspray 7500E
|
Vixen 500E
|
|
Table 2 USA:
|
AN/APG-63(V3)
|
AN/APG-77
|
AN/APG-79
|
AN/APG-81
|
AN/APG-82 (V)1
|
AN/APQ-181
|
AN/APS-149
|
AN/ASQ-236
|
|
AN/ZPY-1 1
|
AN/ZPY-2 2
|
MESA
|
MFAS
|
RACR
|
SABR
|
VADER
|
|
1 “Starlite”
2 Previously known as MP-RTIP
Land-based AESAs:
As many as possible land-based AESAs identified:
#11 in Europe, #10 in USA*.
Column charts of annual shipments & monetary markets (including forecasts to 2017) for:
The AESA systems.
TRMs within these AESA systems.
* Of which 3DELRR and BMEWS cannot yet be quantified.
The land-based AESAs identified are:
Table 3 Europe (includes Israel):
|
BUR
|
EL/M-2080 Green Pine
|
KRONOS 3D LND 1
|
GM 400
|
Selenia ALE
|
SPEXER 500
|
SPEXER 1000
|
SPEXER 1500
|
|
SPEXER 2000
|
TRS-4D
|
Super Green Pine
|
|
|
|
|
|
Table 4 USA:
|
AN/TPN-31 ATNAVICS
|
AN/TPQ-53 (was EQ-36)
|
AN/TPS-80 (G/ATOR)
|
AN/TPY-2 (THAAD-GBR/FBX-T)
|
HAMMR
|
KRONOS 3D LND 1
|
MPAR
|
PAR-2000
|
|
3DELRR
|
BMEWS
|
|
|
|
|
|
|
1 KRONOS 3D LND is manufactured in the US by DRS Technologies which is owned by Selex ES (details in Common Module).
Shipboard AESAs:
As many as possible shipboard AESAs identified:
#10 in Europe, #6 in USA & Australia
Column charts of annual shipments & monetary markets (including forecasts to 2017) for:
The AESA systems.
TRMs within these AESA systems.
The shipboard AESAs identified are:
Table 5 Europe (includes Israel):
|
APAR
|
Artisan 3D
|
EL/M-2248 MF-STAR
|
EL/M-2258
|
KRONOS 3D NV 1
|
RAN-40L
|
SEAMASTER 400 (‘SMILE’)
|
SEAWATCHER-100 (‘SEASTAR’)
|
|
SMART-L
|
SMART-S Mk2
|
|
|
|
|
|
|
Table 6 USA & Australia:
|
AN/SPY-3 2
|
AN/SPY-4 2
|
CEAFAR (Australia)
|
CEAMOUNT (Australia)
|
FlexDAR
|
KRONOS 3D NV 1
|
|
|
1 KRONOS 3D NV is manufactured in the US by DRS Technologies which is owned by Selex ES (details in Common Module).
You need your copy of this report so that you can plan in detail your strategies for addressing these substantially changing market scenarios and appropriate product technologies.
