The Worldwide Industry & Regional Market Opportunities with forecasts to 2017 for Active Electronically-Scanned Array Radars (AESAs), their TRMs and Semiconductors Update Report (Code name: AESAs3)
Worldwide & Regional Market Forecasts for Systems, TRMs & AESA-implemented MMICs
An Extensively Updated 239-page Report from ENGALCO
Prospectus
Researched & prepared by Senior Engalco Staff
AESAs3 comprises 239 pages. There are 144 charts (including 120 data charts) and 113 tables (including 100 data tables)
Global in scope with Europe, North America and the Rest of the (“West-friendly”) World segmentations AESAs3 comprises an extensive and intensive report providing detailed information on the current status and (most importantly) forecast shipments plus RF modules and MMICs market values applying to AESAs. AESAs3 is the heavily updated third-release report in Engalco's sequence of reports on this subject (starting in 2007). Major new developments have occurred or are on the visible horizon, necessitating the generation of this major update report.
The one outstanding new development is definitely Northrop Grumman’s LEMV (long endurance multi-purpose vehicle) which represents a dramatic development in terms of AESA size. The first prototype LEMV (2014) is planned to have >100,000 TRMs and the final two systems will each have 7M TRMs.
Further important examples of new developments include:
Artisan 3D (Europe), CAEW (Israel), CEAMOUNT(Australia), E-CAPTOR (Europe), EQ-36 (USA) and Kronos 3D (LND and NV – Europe). It should also be observed that changes resulting from defense budgetary pressures (notably in the USA and the UK) are, somewhat ironically often favorable to AESA implementations – especially upgrades onto, for example, earlier aircraft such as F-15s or F-16s.
Active, electronically steered arrays (AESAs) are increasingly being implemented into (mainly military) systems currently and there is substantial mileage for important new developments. For some decades the potential advantages have been well known in terms of having a radar beam that could be scanned at orders-of-magnitude faster rates than available mechanically.
In earlier instances the fundamental high-power signal for phased arrays was obtained from a microwave tube source such as a TWT the output of which was separated to feed typically some tens through hundreds of individual antenna elements. The advent of MMICs for both transmit and also for receive functions has transformed the technology and functionality associated with such arrays. Therefore, with this updated report, we are concentrating exclusively on AESAs.
Demand for radars is steadily increasing-both commercial and (especially) military.
The "War against Terrorism" and the campaigns in both Afghanistan and Iraq have continued to drive upwards electronics requirements in defense and security applications. This applies to airborne, battlefield, naval and (to a limited extent) space-based radars.
In this report we cover in depth a study of the various types of AESAs, their production and developmental status, specific examples of airborne, shipboard/naval, land-based, and spaceboard phased array radars. We also include a study of the components and subsystems used in such arrays and provide competitive assessments of key players in this industry-including the systems integrators and principal consortium members. Major examples are: EADS Defence Electronics (notably Cassidian), Galileo Avionica, INDRA, Israel Aerospace Industries (IAI), Northrop Grumman, Raytheon Company, Saab Microwave Systems, Selex Galileo-and Thales.
Underlying technology and impacts
Bearing in mind the importance in this segment of RF/microwave amplifiers and signal sources, specifically the modular products providing these functions, appropriate technologies are also considered from time to time in this report. This particularly includes the semiconductors GaAs, GaN (becoming very significant) and SiC and transmit-receive modules (TRMs) implementing MMICs built using selected chip-sets comprising these semiconductor materials.
Examples of references consulted for updated information include, mainly on the supply-side: exhibition-originated data (e.g. IMS/MTT-S 2010), on-going issues of the Microwave Journal, Microwaves & RF and Microwave Product Digest. On the Demand Side magazines such as Aviation Week & Space Technology and Janes Defense Weekly are regularly consulted. Important useful web links include: Military & Aerospace Electronics, Microwave Flash and RF Globalnet. Most importantly, regular contact is maintained with appropriate industry executives the majority of whom are well known to Engalco.
Engalco's first report on AESAs, including the associated TRMs and MMICs, was released in February 2007. Since that time several important changes have occurred both at the AESA application and platform installation levels and also, critically, at the underlying levels of disruptive product technology. Whilst GaAs MMICs are extensively implemented in today’s AESAs, GaN devices will “invade” the markets with a few years and all the AESAs3 reported data fully accounts for this disruptive trend – in detail.
You need your copy of this report so that you can plan in detail your strategies for addressing these substantially changing market scenarios and appropriate product technologies.
